Ceramic Audio Apc Sc Bare Fiber Optic Adapter For Connection

Shenzhen Haiyu Optics Communication Equipment Co., Ltd.
Contact Now

Ceramic Audio Apc Sc Bare Fiber Optic Adapter For Connection

Place of Origin : Guangdong, China

Brand Name : HYG

Supply Ability : 100000 Piece/Pieces per Week sc/apc bare fiber optic adapter/ sc/apc fiber optic adapter

Packaging Details : Neutral Packing 2000pcs/ctn 25pc/box

MOQ : 50 Piece/Pieces

Price : $0.10 - $1.00 / Piece

Title : sc/apc bare fiber optic adapter

Color : blue/selver/green

caps diameter (mm) : 0.125 ~ 0.127 (0.140mm is available)

caps diameter (2) (mm) : ± 0.001 for MM

sheath diameter (mm) : 0.9/2.0/3.0

Insertion loss : SM=<0.2dB

reflection attenuation : PC>= 45 dB, UPC>= 50 dB, APC>= 65 dB

Interchangeability : ≤0.20 dB

Repeatability : ≤0.10 dB

Storage temperature : -40~85℃

Port : shenzhen

Contact Now

Professional Manufacture usb optical audio adapter wholesale

Our company from the United States and Japan imported from optical passive components production assembly equipment and testing instrument, the formation of optical passive production line. At present, can provide traditional FC, SC, ST fiber connector and LC, double SC, MT - RJ, MU such as small optical fiber connector, all provide optical fiber connection activities connector all through the ministry of information industry optical communication product quality supervision and inspection center for qualified.

sc/apc bare fiber optic adapter/ sc/apc fiber optic adapter/ st fiber optic adapter

Product characteristic

compatibility, repeatability

high precision size has good compatibility

resistance to friction ceramic casing

environmental stability good

card lock plug

provide separate ST type, SC type, FC type, LC type and so on many kinds of adapter

sc/apc bare fiber optic adapter/ sc/apc fiber optic adapter/ st fiber optic adapter

Application

any optical fiber connection

fiber to the home, optical fiber sensors, testing instruments, such as optical fiber point

sc/apc bare fiber optic adapter/ sc/apc fiber optic adapter/ st fiber optic adapter

technical parameters

material:ceramic

repeatability: ≥1000 times

insert loss: SM ≤0.2 dB, MM ≤ 0.3 dB

compatibility: ≤ 0.2 dB

sc/apc bare fiber optic adapter/ sc/apc fiber optic adapter/ st fiber optic adapter

Optical Parameter

W/Japanese Ceramic Sleeve

W/Chinese Ceramic Sleeve

W/P.B Sleeve

Insertion Loss

<0.1 dB

<0.2dB

<0.3dB

Durability

<0.10 dB typical change,1000 times

<0.2dB typical change,1000 times

<0.30 dB typical change,500 times

Operating Temp

-20~75°C

Storage Temp.

-40~85°C

sc/apc bare fiber optic adapter/ sc/apc fiber optic adapter/ st fiber optic adapter

Ceramic Audio Apc Sc Bare Fiber Optic Adapter For ConnectionCeramic Audio Apc Sc Bare Fiber Optic Adapter For ConnectionCeramic Audio Apc Sc Bare Fiber Optic Adapter For Connection

Ceramic Audio Apc Sc Bare Fiber Optic Adapter For Connection
